Motorcycle chain

Product Parameters

CHANGZHOU GOOD-JOB INDUSTRY is leading suppller of motorcycle chain with well-equipped testing equipment and strong technical force. Our factory has over 10years experience or producing chains,specially in motorcycle chain ,428,428H,420,420H,415,415H 520H and so on. With a wide range, good quality, reasonable prices and stylish designs, our products are extensively used in motorcycle and other industries. At the same time ,we will supply you satisfied service for the information of our factory. And we can produce according to your design. We must do our best to meet your need.and quota the best quotation.

Material	Plate: 40Mn steel
	Pin : 30CrMnTi
	Roll : 10 steel
	Bush: 20MN
Pitch	428 428H 420 420H 415H 428HO 12.7mm
Pitch	520 520H 530 530H 520HO 15.875mm
Plate Thickness	428H 2.0MM 428 1.6MM 420 1.5MM 420H 1.8MM
Plate Thickness	415H 1.5MM 520H 2.4MM 428HO 2.0MM 520HO 2.4MM
Standard	GB/T 14212
Ultimate Tension	428H ≧21KN 428 ≧ 18KN 420 ≧ 16KN
Ultimate Tension	415H ≧15.6KN 520H ≧30.1KN 428HO ≧ 22KN 520HO ≧26.5KN
Technology	]. Heat Treatment
	2. Four Side Riveting
	3. Lubricate with Grease
	4.Shot peening surface
Processing Equipment	high-precision and high-speed punching machine.
	High speed punch carbonitriding converter .
	surface shot blasting machine .
	Chain plate automatic string machine.
	High-speed assembly machine .
	Static load testing machine.
MOQ	1000pcs(simple package without any words)
MOQ	5000pcs(color package with customer’s logo)
Delivery Time	15-30 days after T/T 30% deposit as ususl. It will based on the detailed order quantity
Colors	Natural, Yellow,Blue,Gold and Nickel colors.
Package	Inner: Plastic bag.
	Outer : paper box 25pcs in a normal of carton:44CM23.5CM12CM
	Special packing according to client requirement.
